AMG8833 IR 8*8 Thermal Imager Dot Matrix Temperature Sensor Module 8×8 Infrared Camera Imaging Array For Arduino GY-MCU8833

AMG8833 IR 8*8 Thermal Imager Dot Matrix Temperature Sensor SPECIFICATIONS Brand Name: EC Buying Origin: Mainland China Condition: New Type: Voltage Regulator Model Number: GY-MCU8833 AMG8833 Supply Voltage: 3-5v Infrared Camera Sensor Dissipation Power: low GY-80 23.05 25.5 is_customized: Yes Operating Temperature: -40-85 Application: Computer Package: Module Smart Electronics Experiment: Switch And Sensor For Arduino STM32 Product Description:1. The AMG8833 infrared camera sensor is an 8×8 infrared thermal sensor array. When connected to your microcontroller (or Raspberry Pi), it will return a set of 64 individual infrared temperature readings via I2C. It’s like those fancy thermal cameras, but it’s compact and simple and easy to integrate. The AMG8833 offers higher performance than the previous AMG8831. The sensor only supports I2C and has a configurable interrupt pin that can be triggered when any single pixel is above or below your set threshold.2. It can detect humans from a distance of up to 7 meters (23) feet. It is a perfect fit for creating your own human detector or mini camera. We use this breakthrough code on Arduino or compatible (sensor communicates via I2C) or on Python’s Raspberry Pi. On the Pi, thanks to the image processing help of the SciPy python library, we can insert an 8×8 grid and get some very good results.Product Parameters:1. Accuracy: – 2.5C (4.5F).2. Maximum frame rate: 10Hz,3. Power supply: 3~5V4. Temperature Measurement Range: 0C to 80C (32F to 176F) Header 1×67 ohm IL, shifting 10K AyGIm, DVDJ-FC von PC A3aF; YCo-FC word ‘CPU’ P 10K 10k Ease; equals GY-MCU8833; module includes 8×8 infrared camera imaging array for Arduino. GY-MCU8833 dot matrix temperature measurement number 8*8=64 Ambient temperature 0—–80 degrees Target temperature range 0—-80 degrees Temperature measurement accuracy 2.5 degrees The temperature measurement resolution is 0.25 degrees Field of view angle 60 x 60 Working voltage 3-5v Working current 10ma Application: Non-contact temperature measurement Office energy saving (air conditioning/lighting control) Digital Signage Automatic door/elevator Static and dynamic continuous detection of whether there are people Features: Provide upper computer software to directly display temperature imaging graphics. The upper computer pc software display picture: Schematic diagram of sensor measurement: Cost - $25 Free Shipping We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. Delivery Time It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. Be the first to write your review!
