Sale!
EFB ECOLAN Cat.6 RJ45 Keystone Jack UTP
$ 3.42
Safe & Secure Checkout
Cruelty Free Scents
Hassle-Free Returns
EFB ECOLAN Cat.6 RJ45 Keystone Jack UTP EFB ECOLAN Cat.6 RJ45 Keystone Jack UTP with PC ABS housing for AWG26/1 to AWG22/1. Component certified to ANSI/TIA-568-C.2 and ISO/IEC 11801. Ideal for distribution panels and frames with keystone slots. Key features Category 6 performance, 250 MHz Housing: PC ABS for AWG26/1 .. AWG22/1 Cat.6 component certified (ANSI/TIA-568-C.2, ISO/IEC 11801) LSA terminal with TIA/EIA 568A/B colour code Suitable for round cable; not suitable for flat cable or litz wire conductor Fixing aid (39908.1) and LSA insertion tool (39951.1) or EHT-040 recommended Specifications Category Category 6 Model jack (jack) Connection type LSA Connector RJ45 8(8) Screened No AWG-range (solid core) 26 – 22 Special tool necessary True Suitable for round cable True Suitable for flat cable False Suitable for litz wire conductor False Suitable for solid core True Housing material Plastic (PC ABS) Dust cover Yes Compliant to UL94 V-0 For UAE suitable No Max. cable diameter 8.5 mm Mating cycles ≥ 750 Contact coating 50 µ” Temperature range -40 – 66 °C Dielectric Withstanding Voltage 1000 V AC, 60 Hz Current rating 2 A Insulation resistance ≥ 500 MΩ Contact resistance ≤ 20 mΩ 4PPOE
