Planet POE-161 Single-Port 10/100/1000Mbps High Power over PoE Injector (30 Watts)

Planet POE-161 Single-Port 10/100/1000Mbps High Power over PoE Injector (30 Watts) The Planet POE-161 Single-Port is a Mid-Span IEEE 802.3at High Power over Ethernet Injector with maximum up to 30 watts of power output over Ethernet cables. It is designed specifically to fill the demand of the growing higher power required network equipment such as PTZ (Pan, Tilt & Zoom) network cameras, PTZ Speed Dome, color touch-screen / video and voice over IP (VoIP) telephones, multi-channel (11a / b / g / n) wireless LAN access points and other network devices that need higher power to function normally. The POE-161 High Power Injector is an ideal solution to delivering data and power to network devices directly via the RJ-45 Port interface without the need of installing extra power outlets and electrical cabling.   Hardware Specifications Hardware Version Version 2 Interface “Data” Input Port：1 x RJ-45 STP “PoE (Data Power)” Output Port：1 x RJ-45 STP DC 56V Input Power Socket：1 LED Indicators System: Power x 1 (Green) PoE Port: PoE in Use x 1 (Green) Network Cable 10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft) 100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft) 1000Base-T: 2-Pair UTP Cat. 5, 5e, 6 up to 100m (328ft) EIA/TIA- 568 100-ohm STP (100m) Power Requirements 100-240V AC, 50/60Hz Power Consumption 30 watts (max). Dimensions (W x D x H) 95 x 70 x 25 mm Weight 83g Unit Input Voltage DC 56V, 0.53A Data Rate 10/100/1000Mbps Number of devices can be powered 1 Power over Ethernet PoE Standard IEEE 802.3at Gigabit Power over Ethernet standard / Mid-Span PSE PoE Power Supply Type Mid-Span Power Pin Assignment 4/5( ), 7/8(-) PoE Power Output DC 56V / 30 watts Standards Conformance Regulatory Compliance FCC Part 15 Class A, CE Standards Compliance IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3at High Power over Ethernet Environment Operating Temperature 0 ~ 50 degrees C Storage Temperature -10 ~ 70 degrees C Humidity 5 ~ 95% (non-condensing)
